Forney 190 AC/DC MP Welder

The Forney 190 AC/DC Multi-Process welder is one of the most versatile machines on the market and comes out of the box ready to weld virtually anything. The ability to weld up to 3/8” combined with 10-190 AMPs of welding power makes this machine a great tool for professionals and DIY'ers alike. Set & Forget Despooler technology automatically sets the perfect spool tension, optional TruSet™ control sets optimal welding parameters, and Pulse TIG technology excels on thin and/or heat sensitive materials, such as aluminum. This machine is rugged and technologically advanced with a digital display, metal drive system, and 3-year warranty.

PROCESSES:

• AC TIG (AC GTAW)
• DC TIG (DC GTAW)
• TruSet™ MIG (Synergic GMAW)
• MIG (GMAW)
• Flux-Core (FCAW)
• Stick (SMAW)

OUTPUT POWER:

• MIG:
  • 120V: 30A-90A
  • 240V: 30A-190A
• STICK:
  • 120V: 10A-80A
  • 240V: 30A-170A
• TIG:
  • 120V: 10A-110A
  • 240V: 30A-190A

INPUT POWER:

• 110V
• 240V

WELDING CAPACITY (SINGLE PASS):

• 120V: 24 ga - 1/4"
• 240V: 24 ga - 3/8"

WIRE DIAMETER:

• .024" - .035"

ELECTRODE DIAMETER:

• 120V: 3/32" - 1/8"
• 240V: 3/32" - 5/32"

FOR USE ON:

• Mild Steel
• Sheet Metal
• Aluminum
• Stainless Steel
• Copper
• Nickel

FEATURES:

• TruSet™ MIG: Automatically sets the right parameters for your weld setup
• Set & Forget Despooler: This innovative system automatically sets the perfect spool tension, making spool changes effortless.
• Advanced TIG Features: Pulse TIG Welding for thin materials allowing for control over heat input; AC +/- Balance to tailor your arc; and AC Hz Frequency to control your arc and travel speeds.
• Euro Torch Connection: Allows for quick torch attachment and removal, ensuring a proper torch alignment every time.
• Dual-Gas Input: Separate MIG & TIG gas inputs
• Dual-Voltage: 120V and 240V
• Built Tough: Constructed with an all-metal case, built tough to take on the day to day.
• Accessory Compatibility:
  • Foot Pedal- Included!
  • TIG torch- Included!
  • Euro Connect MIG Gun- Included!
  • Spool Gun Capable (Sold separately)
• Lightweight and portable: Allowing for easy movement to any welding project or location.
• Torch Wrap Handle for Cable Organization: Built in organization to keep your workstation clear
• Quick & Simple Polarity Change Over: Connectors on the front of the machine allow for easy polarity changes.
• Generator Compatible
  • 120 V - 4,000W / 240 V - 10,500 W
  • Continuous output (no low-idle)
  • 5% Maximum Total Harmonic Distortion (THD)
• Certification: CSA listed

Warranty:

• 3-year

INCLUDED ACCESSORIES:

• MIG Torch, Euro Connect with 10’ Cable
• TIG Torch, 17F with 12’ Cable
• Electrode Holder with 8’ Cable
• Ground Clamp with 8’ Cable
• Foot Pedal
• Gas Hose, 6’
• Flowgauge regulator
• 240V-120V Adapter
• Spare Consumables
• Forney Expert-Tech™ Tool
• Forney Expert-Tech™ Magnet

UNIT SPECIFICATIONS:

• Unit Weight: 74 lbs. (33.5 Kg)
• Unit Dimensions: 14.13” (359 mm) x 24.5” (622 mm) x 19” (483 mm)

RECOMMENDED FORNEY ACCESSORIES AND CONSUMABLES:

• Forney ITEM#: 85650 (Spool Gun)
• Forney ITEM# 85364 (Argon/CO2 Flow Meter)
• Forney ITEM#: 85658 (17F Standard TIG Torch)
• Forney ITEM#: 85655 (TIG Foot Pedal For MP Welders)
• Forney ITEM#: 85660 (Forney PRO-Grip 17F Amptrol TIG Toch Package, 12.5 ft, with Accessories Kit)
• Forney ITEM#: 60170 (Tip, Tweco® 11-23, 4pk)
• Forney ITEM#: 60171 (Tip, Tweco® 11-30, 4pk)
• Forney ITEM#: 60172 (Tip, Tweco® 11-35, 4pk)
• Forney ITEM#: 85339 (Diffuser, Tweco® 35-50)
• Forney ITEM#: 85336 (Nozzle, Tweco® 21-50)
• Forney ITEM#: 85337 (Nozzle, Tweco® 21-62)
• Forney ITEM#: 100356 (Liner)
• Forney ITEM#: 84094 (Replacement MIG Torch)
• Forney ITEM#: 85669 (Replacement Electrode Holder (25 Dinse))
• Forney ITEM#: 85667 (Replacement Ground Cable Assembly 150A)
• Forney ITEM#: 78036 (Replacement 240V-120V Adapter)
• Forney ITEM#: 85610 (Replacement Foot Pedal, Replacement)
• Forney ITEM#: 78038 (Replacement Drive Roll, .023" & .030")
