Forney 190 MIG Welder, 230V

The Forney 190 MIG Welder is a versatile machine for farms, automotive, boats, general fabrication and repair welding.

190 MIG WELDER SPECIFICATIONS

• Welding Processes: MIG (GMAW) and Flux-Cored (FCAW)
• Amperage Range: 35-190A
• Wire Diameter Range: .024 in - .035 in
• Rated Output: 120 Amps at 25% Duty Cycle
• Plate Thickness Range: 24 gauge - 3/8 in
• Machine Weight: 63 lbs.
• Input Power: 230V
• Duty Cycle: 15% at 140 Amps; 25% at 120 Amps; 60% at 80 Amps; 100% at 60 Amps

FEATURES AND BENEFITS

• Euro Connect Torch with Tweco® style consumables
• Fast disconnect to swap out torch, clean liner
• Upgraded cast aluminum wire drive system for better wire feeding
• Dual geared idler and drive roll with better de-spooler for better wire feeding
• Larger machine cabinet for easy access to 4 in (1-2 lb.) and 8 in (10-11 lb.) spools
• Integrated feet
• Torch wrap included for cable organization
• Torch with built in strain relief which extends cable life

INCLUDES

• MIG gun with 10ft lead
• 10 ft ground cable and clamp
• 15 ft input power cable
• Gas hose and regulator

Forney Industries green color is a federally registered trademark and cannot be reproduced unless authorized by Forney Industries.

318 - Manual.pdf
318 - Quick Start Guide.pdf
318 - Settings Chart.pdf
318 - Spec Sheet.pdf

30 Days

• Product: Free of defects in material and workmanship that may occur under normal use and care.

90 Days

• Welder and Plasma Machines: MIG guns and plasma torches.

3 Years

• Forney Transformer Based Machines: All internal electrical components that cannot be accessed without removing the cover. The transformer and rectifiers are covered by the 5-year warranty.
• Forney Inverter Based Machines: All internal electrical components that cannot be accessed without removing the cover.

5 Years

• Forney Transformer Based Machines: Transformers and rectifiers.

For more warranty information, visit:Forney Industries Warranty Information
